Remove the two lower bracket retainers indicated

in the figure.

Disconnect the electric wiring and the fuel pipes.

See also

Footrest

Remove the chassis central cover.

Remove the footrest.

Remove the three tank retainers.

MP3 125 Chassis

CHAS - 13
