Check the continuity of the yellow - red cable be-
tween the pressure switch connector and the fuse-
box and between the remote control base and the
fuse-box.
With a multimeter, also check the pressure switch
operation as well as the continuity at rest as this is
normally closed switch.
PRINCIPLE DIAGRAM FOR TILT LOCKING ELECTRICAL SYSTEM
MP3 125 Suspensions
SUSP - 31
