Removal
- Place the scooter on its centre stand;
- Remove the swinging arm/engine fitting shown in
the photo
- Move the engine back
- remove the spring anchoring the swinging arm to
the frame as shown in the photo
- Remove the two screws fixing the buffer support
bracket to the frame
- Undo the nut on the LHS shown in the figure and
remove the corresponding bolt from the opposite
side.
- Remove the swinging arm.
MP3 125 Suspensions
SUSP - 49
