Removal
Remove the split pin.
Use new split pins when refitting.
Undo the wheel hub nut.
- When refitting, secure to the specified torque.
Locking torques (N*m)
Wheel axle nut 74 ÷ 88
Remove the seeger ring, after that, remove the
hub with the help of a rubber mallet slightly hitting
on the brake disc side, turning the wheel hub at the
same time.
Loosen the 6 screws indicated in the figure and
remove the brake disc from the wheel hub.
- When refitting, secure to the specified torque.
Recommended products
Loctite 242 product description
Apply LOCTITE medium type 242 threadlock
MP3 125 Braking system
BRAK SYS - 3
