- Remove the key switch plastic ring and the two
plastic covers near the footrest.
- Remove the five screws on the shield back plate
rear part.
- Remove the two shield back plate front screws,
see figure.
- Remove the two shield back plate lower screws.
- Remove the external temperature sensor con-
nection.
See also
Legshield
spoiler
MP3 125 Chassis
CHAS - 7
