Side fairings

SIDE COVERS

Code Action Duration

1 004036 Lower chassis cover - Re-

placement

2 004129 Rear fairing - Replacement

3 004085 Fairing (1) - Replacement

4 004068 Passenger handgrip - Re-

placement

5 004037 Side aprons-Replacement

Time MP3 125

TIME - 24
