Pioneer MEP-7000 Service Manual

16
MEP-7000
1
2 3 4
A
B
C
D
E
F
1
2 3 4
Points to be checked about the EJECT guard
Point to be checked when reassembling:
Check that the hooks are properly engaged.
OK: No lifting when visually checked
Bend the hooks according to the printed indications pointed out here, in the order of A, B, C, then D.
When attaching the OELB unit to the DISP Assy, perform additional soldering.
Point soldering
The holes need not be filled.
NG: Lifted
