Pioneer MEP-7000 Service Manual

193
MEP-7000
5
6 7 8
5
6 7 8
A
B
C
D
E
F
Measurement condition of IC506 and IC507 :
Play style: Normal (The control unit and the drive unit are connected.)
Measurement mode : CD playback mode of Disk 1 and Disk 2, Pioneer Test disc (STD-905 Track 2)
Measurement condition of IC403 :
Play style: Normal style + USB storage devices (USB 1 & USB 2)
(Conditions where the control unit and the drive unit are connected and where USB storage devices are connected
to the USB 1 [A-type] and 2 [A-type] ports)
Measurement mode : Idling (State when the AC power is set to ON)
Pin No. Voltage(V) Pin No. Voltage(V)
1 1.60 15 5.00 Vin
2 1.20 16 2.50
31.60 17 N.C.
4 N.C. 18 2.50
5 1.50 19 0.00 G
6 N.C. 20 5.00 Vin
7 0.00 G 21 2.20
8 5.00 Vin 22 5.00
9 5.00 Vin 23 0.00
10 0.00 G 24 N.C.
11 2.50 25 N.C.
12 N.C. 26 0.00
13 2.50 27 0.00
14 0.00 G 28 3.30
Pin No. Voltage(V) Pin No. Voltage(V) Pin No. Voltage(V) Pin No. Voltage(V)
13.30Vin17 N.C. 33 N.C. 49 3.30
23.10 18N.C. 34 3.30 50 3.30
3 0.00 19 0.00 35 3.30 51 3.30
4 0.00 G 20 3.30 36 0.00 52 3.30
50.00 21 N.C. 37 N.C. 53 0.00 G
6 0.00 22 0.00 38 3.30 54 1.80Vin
7 3.30 Vin 23 3.30 39 N.C. 55 0.00 G
8 0.00 24 0.00 40 3.30 56 N.C.
9 0.00 25 0.00 41 0.00 G 57 N.C.
10 0.00 G 26 N.C. 42 1.80Vin 58 1.66
11 N.C. 27 0.00 43 3.30 59 0.00
12 N.C. 28 3.30 Vin 44 3.30 60 1.80
Vout
13 3.30 Vin 29 0.00 G 45 3.30 61 3.30
Vout
14 N.C. 30 1.80 Vin 46 3.30 62 3.30
15 N.C. 31 0.00 47 3.30 63 1.20
16 0.00 G 32 N.C. 48 0.00 64 0.00 G
IC506,IC507 PE8001A
DAC
IC403 USB2504A-JT
USB HUB

Pioneer MEP-7000 Specifications

General

Frequency range	4 - 20000 Hz
Channels quantity	- channels
Digital sound processing	- bit
Total Harmonic Distortion (THD)	0.006 %
Dimensions (WxDxH)	483 x 325 x 91 mm
Power consumption (typical)	33 W

Weight and Dimensions

Weight	6100 g
