Pioneer MEP-7000 Service Manual

195
MEP-7000
5
6 7 8
5
6 7 8
A
B
C
D
E
F
Pin No. Voltage(V) Pin No. Voltage(V) Pin No. Voltage(V) Pin No. Voltage(V)
1 N.C. 26 N.C. 51 1.80763.30
2 N.C. 27 N.C. 52 1.8077 N.C.
3 N.C. 28 0.00 53 1.8078N.C.
4 N.C. 29 3.30 54 0.00 79 N.C.
5 N.C. 30 3.30 55 0.00 800.00
6 0.00 31 3.30 56 0.00 813.30
7 0.00 32 3.30 57 0.00 823.30
8 0.00 33 2.00 58N.C. 833.30
9 N.C. 34 0.00 59 N.C. 843.30
10 0.00 35 0.00 60 3.30 Vin 853.30
11 N.C. 36 3.00 61 N.C. 863.30
12 0.00 G 37 N.C. 62 0.00 G 87 N.C.
13 1.60 38N.C. 63 0.00 88 N.C.
14 3.30 Vin 39 0.00 64 0.00 89 N.C.
15 3.30 40 N.C. 65 3.30 90 N.C.
16 N.C. 41 N.C. 66 0.00 91 N.C.
17 N.C
. 42 N.C. 67 3.30 92 N.C.
18N.C. 43 N.C. 68 3.30 93 N.C.
19 N.C. 44 3.30 69 3.30 94 0.00 G
20 N.C. 45 N.C. 70 3.30 95 N.C.
21 N.C. 46 N.C. 71 N.C. 96 3.30 Vin
22 N.C. 47 N.C. 72 N.C. 97 3.30 Vin
23 3.30 48N.C. 73 N.C. 98N.C.
24 3.30 49 N.C. 74 N.C. 99 3.30
25 N.C. 50 N.C. 75 N.C. 100 N.C.
Pin No. Voltage(V) Pin No. Voltage(V) Pin No. Voltage(V) Pin No. Voltage(V)
1 3.30 12 2.70 23 1.10 34 3.30
2 N.C. 13 3.30 24 0.00 G 35 3.30
3 3.30 14 2.50 25 1.40 36 0.00 G
4 0.00 G 15 3.00 26 0.00 37 1.66
5 3.30 16 0.00 G 27 1.30 38 0.00
6 3.30 17 3.30 Vin 28 1.40 39 0.00
73.30 18 3.20 29 3.30 Vin 40 0.00
8N.C. 19 2.90 30 0.00 G 41 3.30 Vin
9 3.30 Vin 20 3.30 31 1.27 42 2.75
10 3.30 21 N.C. 32 3.30 43 N.C.
11 0.00 G 22 1.20 33 1.35 44 3.30
Measurement condition of IC706 :
Play style: Manipulator style
(Conditions where the PC in which the USB driver dedicated to the MEP-7000 has been installed is connected)
Measurement mode: State when the USB bus power is set to ON
Pin No. Voltage(V) Pin No. Voltage(V) Pin No. Voltage(V) Pin No. Voltage(V)
1 1.00 17 2.50 33 0.00 49 1.00
21.00 18 2.50 34 0.00 50 3.30
3 1.00 19 2.50 35 3.30 Vin 51 3.30
4 0.00 20 2.50 36 3.30 52 3.30
5 3.30 Vin 21 3.30 Vin 37 3.30 53 2.44 Vin
6 1.20 22 2.50 38 0.00 54 0.00 G
7 0.60 23 2.50 39 N.C. 55 3.30 Vin
8 1.20 24 2.50 40 3.30 56 3.30
9 0.50 25 2.30 41 3.30 57 3.30
10 2.44 Vin 26 2.30 42 2.44 Vout 58 3.30
11 3.30 27 2.30 43 3.30 Vin 59 0.00
12 3.30 28 0.00 G 44 0.00 G 60 0.00
13 3.30 29 2.44 Vin 45 3.30 Vin 61 0.00 G
14 0.00 30 3.30 46 4.80622.44Vin
15 0.00 G 31 N.C.473.30 631.30
16 2.30 32 N.C. 48 0.00 64 1.50
IC1700 PDY084A8
CPLD
IC800 PEG481A
CENTER PANEL
.COM
IC706 TDOTG242-0F0C8
USB CONTROLLER
