Pioneer MEP-7000 Service Manual

232
MEP-7000
1
2 3 4
A
B
C
D
E
F
1
2 3 4
143
144
145
REMOTE CONTROL Communication Waveforms (Input/Output of the Buffer)
BRDG_CLK
CH1
CH2
BRDG_FS
CH1
CH2
BRDG_CS#
CH1
CH2
2.0V/div
2.0V/div
100ms/div
2.0V/div
2.0V/div
100ms/div
100ms/div
2.0V/div
2.0V/div
Idling
Idling
Idling
CH1
BRDG_CLK
INPUT
CH2
BRDG_CLK
OUTPUT
CH1
BRDG_FS
INPUT
CH2
BRDG_FS
OUTPUT
CH1
BRDG_CS#
INPUT
CH2
BRDG_CS#
OUTPUT
No.(SCH/PCB)
CH1 INPUT 170 IC2203(1P)
CH2 OUTPUT 171 IC2203(7P)
No.(SCH/PCB)
CH1 INPUT 172 IC2205(1P)
CH2 OUTPUT 173 IC2205(7P)
No.(SCH/PCB)
CH1 INPUT 174 IC2201(1P)
CH2 OUTPUT 175 IC2201(7P)
[14] NJACK INTERNET COMMUNICATION
Measurement conditions
Voltage
Time
Signal Name
Measurement Point
Measurement conditions
Voltage
Time
Signal Name
Measurement Point
Measurement conditions
Voltage
Time
Signal Name
Measurement Point

Pioneer MEP-7000 Specifications

General

Frequency range	4 - 20000 Hz
Channels quantity	- channels
Digital sound processing	- bit
Total Harmonic Distortion (THD)	0.006 %
Dimensions (WxDxH)	483 x 325 x 91 mm
Power consumption (typical)	33 W

Weight and Dimensions

Weight	6100 g
