233
MEP-7000
5
6 7 8
5
6 7 8
A
B
C
D
E
F
146
147
148
KEY_DATA
CH1
CH2
DISP_DATA1
CH1
CH2
DISP_DATA2
CH1
CH2
2.0V/div
2.0V/div
100ms/div
2.0V/div
2.0V/div
100ms/div
100ms/div
2.0V/div
2.0V/div
CH1
KEY_DATA
INPUT
CH2
KEY_DATA
OUTPUT
CH1
DISP_DATA1
INPUT
CH2
DISP_DATA1
OUTPUT
CH1
DISP_DATA1
INPUT
CH2
DISP_DATA1
OUTPUT
No.(SCH/PCB)
CH1 INPUT 176 IC2202(1P)
CH2 OUTPUT 177 IC2202(7P)
No.(SCH/PCB)
CH1 INPUT 178 IC2207(1P)
CH2 OUTPUT 179 IC2207(7P)
No.(SCH/PCB)
CH1 INPUT 180 IC2207(3P)
CH2 OUTPUT 181 IC2207(5P)
Idling
Idling
Idling
Measurement conditions
Voltage
Time
Signal Name
Measurement Point
Measurement conditions
Voltage
Time
Signal Name
Measurement Point
Measurement conditions
Voltage
Time
Signal Name
Measurement Point
