236
MEP-7000
1
2 3 4
A
B
C
D
E
F
1
2 3 4
155
USB_B
CH1
100ms/div
1.0V/div
DJS play
No.(SCH/PCB)
CH1 DP1 188 L701
CH2 DM1 189 L701
[16] NMAIN_USB
Measurement conditions
Voltage
Time
Signal Name
Measurement Point
