Pioneer MEP-7000 Service Manual

235
MEP-7000
5
6 7 8
5
6 7 8
A
B
C
D
E
F
152
153
154
If communication with the side panel
microcomputer (for A player) failed
CH1
If communication with the side panel
microcomputer (for B player) failed
CH1
During normal operation
CH1
1.0V/div
20µs/div
1.0V/div
20µs/div
20µs/div
1.0V/div
No.(SCH/PCB)
CH1 - 151 IC1700(2P)
No.(SCH/PCB)
CH1 - 151 IC1700(2P)
No.(SCH/PCB)
CH1 - 151 IC1700(2P)
Voltage
Time
Signal Name
Measurement Point
Voltage
Time
Signal Name
Measurement Point
Voltage
Time
Signal Name
Measurement Point
