TABLE V-III. TROUBLESHOOTING CHART (SURFACE CONTROLS) (cont.)
STABLIATOR CONTROL SYSTEM (cont.)
Resistance to stabilator System not lubricated Lubricate system.
control movement. properly.
Cable tension too high. Adjust cable tension
per Paragraph 5-16.
Binding control column. Adjust and lubricate
per Paragraph 5-6.
Pulleys binding or Replace binding pulleys
rubbing. and/or provide clearance
between pulleys and
brackets.
Cables not in place on Install cables cor-
pulleys. rectly.
Cables crossed or Check routing of control
routed incorrectly. cables.
Bent stabilator hinge. Repair or replace
stabilator hinge.
Incorrect stabilator Stabilator stops Adjust stop screws per
travel. incorrectly adjusted. Paragraph 5-16.
Correct stabilator Stabilator cables Rig cables in accordance
travel cannot be incorrectly rigged. with Paragraph 5-16.
obtained by adjusting
stops.
Trouble Cause Remedy
Issued: 12/15/76
CHEROKEE ARROW III SERVICE MANUAL
SURFACE CONTROLS

Piper TURBO ARROW III Specifications

General

Manufacturer	Piper Aircraft
Model	Turbo Arrow III
Horsepower	200 hp
Max Takeoff Weight	2, 900 lbs
Fuel Capacity	72 gallons
Service Ceiling	20, 000 ft
Seating Capacity	4
Type	Single-engine piston
Propeller	Constant-speed
Landing Distance	1, 200 ft
