TABLE V-III. TROUBLESHOOTING CHART (SURFACE CONTROLS) (cont.)
AILERON CONTROL SYSTEM (cont.)
Control wheels not Incorrect control Rig in accordance with
synchronized. column rigging. Paragraph 5-6.
Control wheels not hori- Incorrect rigging of Rig in accordance with
zontal when ailerons aileron system. Paragraph 5-12.
are neutral.
Incorrect aileron Aileron control rods Adjust in accordance
travel. not adjusted properly. with Paragraph 5-12.
Aileron bellcrank stops Adjust in accordance
not adjusted properly. with Paragraph 5-12.
Correct aileron travel Incorrect rigging of Rig in accordance with
cannot be obtained by aileron cables, control Paragraph 5-12.
adjusting bellcrank wheel and control rod.
stops.
Control wheel stops Incorrect rigging Rig in accordance with
before control between control wheel Paragraph 5-12.
surfaces reach full and control cables.
travel.
STABILATOR CONTROL SYSTEM
Lost motion between Cable tension too low. Adjust cable tension
control wheel and stabi- per Paragraph 5-16.
lator.
Linkage loose or worn. Check linkage and
tighten or replace.
Broken pulley. Replace pulley.
Cables not in place Install cables cor-
on pulleys. rectly.
Trouble Cause Remedy
Issued: 12/15/76
CHEROKEE ARROW III SERVICE MANUAL
SURFACE CONTROLS
