TABLE V-III. TROUBLESHOOTING CHART (SURFACE CONTROLS) (cont.)
STABILATOR TRIM CONTROL SYSTEM
Lost motion between Cable tension too low. Adjust in accordance
trim control wheel with Paragraph 5-22.
and trim tab.
Cables not in place on Install cables accord-
pulleys. ing to Paragraphs 5-19.
and 5-21.
Broken pulley. Replace pulley.
Linkage loose or worn. Check linkage and
tighten or replace.
Trim control wheel System not lubricated Lubricate system.
moves with excessive properly.
resistance.
Cable tension too high. Adjust in accordance
with Paragraph 5-22.
Pulleys binding or Replace binding pulleys.
rubbing. Provide clearance between
pulleys and brackets.
Cables not in place on Refer to Paragraphs
pulleys. 5-19 and 5-21.
Trim tab hinge binding. Lubricate hinge. If
necessary, replace.
Cables crossed or Check routing of control
routed incorrectly. cables.
Trouble Cause Remedy
Issued: 12/15/76
CHEROKEE ARROW III SERVICE MANUAL
SURFACE CONTROLS

Piper TURBO ARROW III Specifications

General

Manufacturer	Piper Aircraft
Model	Turbo Arrow III
Horsepower	200 hp
Max Takeoff Weight	2, 900 lbs
Fuel Capacity	72 gallons
Service Ceiling	20, 000 ft
Seating Capacity	4
Type	Single-engine piston
Propeller	Constant-speed
Landing Distance	1, 200 ft
