TABLE V-III. TROUBLESHOOTING CHART (SURFACE CONTROLS) (cont.)
STABILATOR TRIM CONTROL SYSTEM (cont.)
Trim tab fails to System incorrectly Check and/or adjust
reach full travel. rigged. rigging per paragraph
5-22.
Trim drum incor- Check and/or adjust
rectly wrapped. rigging per paragraph
5-22.
Trim indicator fails Trim indicator unit Adjust in accordance
to indicate correct not adjusted properly. with Paragraph 5-22.
trim position.
RUDDER CONTROL SYSTEM
Lost motion between Cable tension too low. Adjust cable tension
rudder pedals and per Paragraph 5-29.
rudder.
Linkage loose or worn Check linkage and
tighten or replace.
Broken pulley. Replace pulley.
Bolts attaching rudder Tighten bellcrank bolts.
to bellcrank are loose.
Excessive resistance System not lubricated Lubricate system.
to rudder pedal properly.
movement.
Rudder pedal torque Lubricate torque tube
tube bearing in need bearings.
of lubrication.
Cable tension too high. Adjust cable tension
Per Paragraph 5-29.
Trouble Cause Remedy
Issued: 12/15/76
CHEROKEE ARROW III SERVICE MANUAL
SURFACE CONTROLS

Piper TURBO ARROW III Specifications

General

Manufacturer	Piper Aircraft
Model	Turbo Arrow III
Horsepower	200 hp
Max Takeoff Weight	2, 900 lbs
Fuel Capacity	72 gallons
Service Ceiling	20, 000 ft
Seating Capacity	4
Type	Single-engine piston
Propeller	Constant-speed
Landing Distance	1, 200 ft
