TABLE VII-III. NOSE GEAR SERVICE TOLERANCES
Manufacturers Service Service
Fig. No Part No Nomenclature Dimension Dimension Tol. Remarks
1 67146-00 Drag link, upper ID .6235 ID .6230 002
.6245 .6250
2 452 474 Bearing, upper drag * * ID .4385 ID .4395 002
(F632-1) link .4375 .4375
3 65003-45* Bushing ID ID
4 67146-00 Drag link upper ID .378 ID .3775 002
.379 .3795
5 452 450 Bearing upper drag * *ID .2495 ID .2495 002
(FF310-5) link .2505 .2515
6 67144-00 Drag link, lower ID .2495 ID .2495 002
.2505 .2515
7 67144-00 Drag link, lower ID .3120 ID .3120 002
.3130 .3140
8 44386-2 Steering arm ID .4370 ID .4370 0015
.4385 .4385
9 14976-11 Bushing, steering arm * * ID .312 ID .312 002 Press fit
.313 .314
10 67054-03 Trunnion housing drag ID .4415 ID .4415 0015
link attachment .4425 .4425
11 67026-07 Bearing trunnion housing ID .312 ID .312 002
drag link attachment .313 .314
12 67054-03 Trunnion assembly main ID .6285 ID .6285 001
attachment fitting .6295 .6295
13 67026-11 Bushing, trunnion * * ID .5000 ID .5000 003
assembly attachment .5015 .5030
* *Line ream to this dimension after
* Used with 452 474 bearing installation of new part
Revised: 2/13/89
1L10
* CHEROKEE ARROW III SERVICE MANUAL
LANDING GEAR AND BRAKE SYSTEM
