TABLE VII-IV. MAIN GEAR SERVICE TOLERANCES
Manufacturers Service Service
Fig. No Part No Nomenclature Dimension Dimension Tol. Remarks
1 67514-0 Link, upperside brace ID .3645 ID
.3625
2 63900-89 Bushing, upperside * * ID .249 ID .248 .004 Press Fit
brace link .251 .252
3 95642-4 Bracket, side brace ID .7495 ID .7490 .002
95642-5 support .7505 .7510
4 67026-12 Bushing, support ID .624 ID .624 Install using
bracket .625 .626 Loctite 601.
5 78717-2 Stud, side brace O D .6235 O D.6220
support .6225
6 78717-2 Stud, side brace ID .4365 ID .4355 .004
support .4385 .4395
7 65003-41 Bushing, side brace ID .373 ID .372 .004
support stud .375 .376
8 67025-2 Link, upperside brace ID .4945 ID .4925
.4935
9 14843-16 (2) Bushing, side brace * * ID .376 ID .374 Press Fit. Install
link .375 using Loctite
601.
10 400 761 Bolt, link, stud O D .373 +0 O D.373 +0 .004
(AN26-25) attaching -.002 -.004
11 67514-0 Link, upperside brace ID .4945 ID .4925
.4935
12 14843-16 (2) Bushing, side brace * * ID .3745 ID .374 Press Fit
link .3755
13 67797-04 Link, lowerside brace ID .4905 ID .500
67797-05 .4925
14 65003-44 (2) Bushing, lowerside brace * * ID .373 ID .372 .004 Press Fit
link .375 3.76
* * Line ream to this dimension after
installation of new part
Revised: 2/13/89
1L13
* CHEROKEE ARROW III SERVICE MANUAL
LANDING GEAR AND BRAKE SYSTEM
