26 - ATR244 - User manual
12 Table of Configuration Parameters
GROUP A -
A . i n .1
- Analogue input 1
1 S EN .1 Sensor AI1
Analogue input configuration / sensor AI1 selection
tc. k Tc-K -260 °C..1360 °C. (Default)
tc. s Tc-S -40 °C..1760 °C
tc. r Tc-R -40 °C..1760 °C
tc. J Tc-J -200 °C..1200 °C
Tc. T Tc-T -260 °C..400 °C
tc. E Tc-E -260 °C..980 °C
tc. N Tc-N -260 °C..1280 °C
tc. b Tc-B 100 °C..1820 °C
Pt10 0 Pt100 -200 °C..600 °C
ni10 0 Ni100 -60 °C..180 °C
ntc NTC 10K -40 °C..125 °C
Ptc PTC 1K -50 °C..150 °C
Pt500 Pt500 -200 °C..600 °C
Pt1k Pt1000 -200 °C..600 °C
0-1 0..1 V
0-5 0..5 V
0-10 0..10 V
0-20 0..20 mA
4-20 4..20 mA
0-60 0..60 mV
Po t. Potentiometer (set the value on parameter 6)
2
d .P. 1 Decimal Point 1
Select number of displayed decimal points for AI1
0 Default
0.0 1 decimal
0.0 0 2 decimals
0.000 3 decimals
3
d eG r. Degree
°C Celsius (Default)
°F Fahrenheit
K Kelvin
4
L.L.i .1 Lower Linear Input AI1
AI1 lower limit only for linear signals. Ex.: with input 4..20 mA this parameter takes value associated
to 4 mA. The value may be greater than the one entered on the next parameter.
-9999..+30000 [digit
1 p. 65
] Default: 0.
5
u.L.i.1 Upper Linear Input AI1
AI1 upper limit only for linear signals Ex: with input 4..20 mA this parameter takes value associated
to 20 mA.The value may be lower than the one entered on the previous parameter.
-9999..+30000 [digit
1 p. 65
] Default:1000
6
P. v A .1 Potentiometer Value AI1
Selects the value of the potentiometer connected on AI1
1..150 kohm. Default: 10kohm
