217 A.6. o . t. Alarm 6 Output Type
Defines the output type if the alarm 6 is analogue.
0.1 0 v Output 0...10 V. Default
4.20 ma Output 4...20 mA.
218
a.6.Hy. Alarm 6 Hysteresis
Alarm 6 hysteresis
-9999..+9999 [digit
1 p. 65
] (degrees.tenths for temp. sensors). Default 0.5.
219
A.6.L.L. Alarm 6 Lower Limit
Lower limit selectable for the alarm 6 setpoint.
-9999..+30000 [digit
1 p. 65
] (degrees for temp. sensors). Default 0.
220
A.6. u .L. Alarm 6 Upper Limit
Upper limit selectable for the alarm 6 setpoint.
-9999..+30000 [digit
1 p. 65
] (degrees for temp. sensors). Default 1750.
221
a .6. re. Alarm 6 Reset
Alarm 6 contact reset type.
A. rEs. Automatic reset (Default)
M. rEs. Manual reset (manual reset by keyboard or by digital input)
M.rEs.S. Stored manual reset (keeps the output status also after a power failure)
222
A.6.S. e. Alarm 6 State Error
Alarm 6 output status in case of error.
If the alarm output is 0-10V:
0 V 0 V. Default 10 v 10 V.
If the alarm output is 0-20 mA or 4-20 mA:
0 ma 0 mA. Default
4 ma 4 mA.
20 ma 20 mA.
21.5 m a 21.5 mA.
223
rES. Reserved
Reserved parmeter
224 a .6. d e. Alarm 6 Delay
Alarm 6 Delay.
-3600..+3600 seconds. Default: 0.
Negative value: delay when exit alarm status
Positive value: delay when enter alarm status
225
A.6.S. p. Alarm 6 Setpoint Protection
Allows or not to change the alarm 6 setpoint.
FrEE Editable by the user (Default)
Lock Protected
Hid E Protected and not visualized
226
A.6.Lb . Alarm 6 Label
Selects the message to be visualized in case of alarm 6 intervention
0 Disabled . Default 0.
1-20 Message 1..20 (see customizable messages table)
227÷230 Reserved Parameters - Group L
Reserved parameters - Group L
