40 - ATR244 - User manual
129 A.1.L.L. Alarm 1 Lower Limit
Lower limit selectable for the alarm 1 setpoint.
-9999..+30000 [digit
1 p. 65
] (degrees for temp. sensors). Default 0.
130
A .1 . u . L . Alarm 1 Upper Limit
Upper limit selectable for the alarm 1 setpoint
-9999..+30000 [digit
1 p. 65
] (degrees for temp. sensors). Default 1750.
131
a .1 . r e . Alarm 1 Reset
Alarm 1 contact reset type
A. rEs. Automatic reset (Default)
M. rEs. Manual reset (manual reset by keyboard or by digital input)
M.rEs.S. Stored manual reset (keeps the output status also after a power failure)
132
A .1 . S . e . Alarm 1 State Error
Alarm 1 output status in case of error.
open Open contact. Default
CLose Closed contact.
133
A .1 . L d . Alarm 1 Led
Defines the status of the led A1 in correspondence of the relevant output
o.c. ON with open contact or DO switched off.
c.c. ON with closed contact or DO switched on. (Default)
134
a .1 . d e . Alarm 1 Delay
Alarm 1 Delay.
-3600..+3600 seconds. Default: 0.
Negative value: delay when exit alarm status.
Positive value: delay when enter alarm status.
135
A .1 . S . p . Alarm 1 Setpoint Protection
Allows or not to change the alarm 1 setpoint
FrEE Editable by the user (Default)
Lock Protected
Hid E Protected and not visualized
136
A .1 . L b . Alarm 1 Label
Selects the message to be visualized in case of alarm 1 intervention
0 Disabled. Default 0.
1-20 Message 1..20 (Vedi tabella messaggi personalizzabili)
137÷140 Reserved Parameters - Group G
Reserved parameters - Group G
