46 - ATR244 - User manual
181 A.4.o.t. Alarm 4 Output Type
Defines the output type if the alarm 4 is analogue.
0.1 0 v Output 0...10 V. Default
4.20 ma Output 4...20 mA.
182
a .4. H y . Alarm 4 Hysteresis
Alarm 4 hysteresis.
-9999..+9999 [digit
1 p. 65
] (degrees for temp. sensors). Default 0.5.
183
A.4.L.L Alarm 4 Lower Limit
Lower limit selectable for the alarm 4 setpoint.
-9999..+30000 [digit
1 p. 65
] (gradi per sensori di temperatura). Default 0.
184
A.4. u . L. Alarm 4 Upper Limit
Upper limit selectable for the alarm 4 setpoint.
-9999..+30000 [digit
1 p. 65
] (degrees for temp. sensors). Default 1750.
185
a .4. re . Alarm 4 Reset
Alarm 4 contact reset type.
A. rEs. Automatic reset (Default)
M. rEs. Manual reset (manual reset by keyboard or by digital input)
M.rEs.S. Stored manual reset (keeps the output status also after a power failure)
186
A.4.S. e . Alarm 4 State Error
Alarm 4 output status in case of error.
If the alarm output is digital (SSR):
off Digital output OFF. Default on Digital output ON.
If the alarm output is 0-10V:
0 V 0 V. Default 10 v 10 V.
If the alarm output is 0-20 mA or 4-20 mA:
0 ma 0 mA. Default
4 ma 4 mA.
20 ma 20 mA.
21.5 m a 21.5 mA.
187
rES. Reserved
Reserved parmeter
188 a .4. d e . Alarm 4 Delay
Alarm 4 Delay.
-3600..+3600 seconds. Default: 0.
Negative value: delay when exit alarm status.
Positive value: delay when enter alarm status
189
A.4.S. p. Alarm 4 Setpoint Protection
Allows or not to change the alarm 4 setpoint.
FrEE Editable by the user (Default)
Lock Protected
Hid E Protected and not visualized
190
A.4. Lb . Alarm 4 Label
Selects the message to be visualized in case of alarm 4 intervention
0 Disabled . Default 0.
1-20 Message 1..20 (Vedi tabella messaggi personalizzabili)
191÷194 Reserved Parameters - Group J
Reserved parameters - Group J
