User manual - ATR244 - 65
14 Table of Anomaly Signals
If installation malfunctions, the controller switches off the regulation output and reports the anomaly
noticed. For example, controller will report failure of a connected thermocouple visualizing
e -05
(flashing) flashing on display.
For other signals see table below.
Cause What to do
E-02
SYSTEM
Erro r
Cold junction temperature sensor failure or
environment temperature out of range
Call assistance
E-04
eeprom
Erro r
Incorrect configuration data.
Possible loss of instrument calibration
Verify that configuration parameters are
correct.
E-05
PRo be 1
Erro r
Sensor connected to AI1 broken or
temperature out of range
Control connection with probes and their
integrity.
E-06
PRo be 2
Erro r
Sensor connected to AI2 broken or
temperature out of range
Control connection with probes and their
integrity.
E-08
SYSTEM
Erro r
Missing calibration Call assistance
E -1 0
a .i n .2
di s a b led
Analogue input 2 disabled but used during
configuration.
Enable A.i n .2 or disable it during configura-
tion.
E-80
rfi d Erro r
Tag rfid malfunctioning Call assistance
Notes / Updates
1 Display of decimal point depends on setting of parameter sen. and parameter d . p.
2 On activation, the output is inhibited if the controller is in alarm mode. Activates only if alarm condition reappers, after that
it was restored.
