Pixsys ATR244 User Manual

66 - ATR244 - User manual
Table of configuration parameters
GROUP A -
A . i n .1
- Analogue input 1
1
S EN .1 Sensor AI1 26
2
d .P. 1 Decimal Point 1 26
3
d eG r. Degree 26
4
L.L.i .1 Lower Linear Input AI1 26
5
u.L.i.1 Upper Linear Input AI1 26
6
P. v A .1 Potentiometer Value AI1 26
7
i.o.L.1 Linear Input over Limits AI1 27
8
o . c A .1 Offset Calibration AI1 27
9
G . c a .1 Gain Calibration AI1 27
10
L t c .1 Latch-On AI1 27
11
c . F L.1 Conversion Filter AI1 27
12
c . F r.1 Conversion Frequency AI1 27
13÷17 Reserved Parameters - Group A 27
GROUP B -
A.i n .2
- Analogue input 2
18
SEN.2 Sensor AI2 28
19
d .P. 2 Decimal Point 2 28
20
rEs . Reserved 28
21
L.L.i .2 Lower Linear Input AI2 28
22
u.L.i.2 Upper Linear Input AI2 28
23
P. v A . 2 Potentiometer Value AI2 28
24
i.o.L.2 Linear Input over Limits AI2 28
25
o . cA.2 Offset Calibration AI2 29
26
G. ca .2 Gain Calibration AI2 29
27
Lt c.2 Latch-On AI2 29
28
c.FL.2 Conversion Filter AI2 29
29
c.Fr.2 Conversion Frequency AI2 29
30÷34 Reserved Parameters - Group B 29
GROUP C -
c m d .1
- Outputs and regulation Process 1
35 c.ou.1 Command Output 1 30
36
c . P r.1 Command Process 1 (only on ATR244-23ABC-T) 30
37
rEs . Reserved 30
38
A c . t .1 Action type 1 30
39
c . H Y .1 Command Hysteresis 1 30
40
L.L.S.1 Lower Limit Setpoint 1 31
41
U . L . S .1 Upper Limit Setpoint 1 31
42
c . r e .1 Command Reset 1 31
43
c . S . e .1 Command State Error 1 31
44
c . L d .1 Command Led 1 31
45
c . d e .1 Command Delay 1 31
46
c . S . p .1 Command Setpoint Protection 1 31
47
v A . t .1 Valve Time 1 31
48
a.ma.1 Automatic / Manual 1 32
49÷53 Reserved Parameters - Group C 32
GROUP D -
cmd.2
- Outputs and regulation Process 2
54
c.ou.2 Command Output 2 (only on ATR244-23ABC-T) 32
55
c.Pr.2 Command Process 2 (only on ATR244-23ABC-T) 32
