56 - ATR244 - User manual
GROUP R -
di s p.
- Display
277 v .FLt Visualization Filter
dis a b. Disabled
ptcHf Pitchfork filter (Default)
fi. o r d. First Order
fi. o r. p. First Order with Pitchfork
2 sa.m. 2 Samples Mean
.... ...n Samples Mean
10.sa.m. 10 Samples Mean
278
vi.d.2 Visualization Display 2
Selects visualization on display 2.
c.1.S Pv Command 1 setpoint (Default)
o u. P e.1 Percentage of command output 1
A.iN.1 Value read on input AI1.
A.i n . 2 Value read on input AI2.
MEAn Arithmetic average of the value read on inputs AI1 and AI2 [(AI1-AI2)/2].
d i F F. Difference of the values read on inputs AI1 and AI2 (AI1-AI2).
A b . d i f. Module of the difference of the values read on inputs AI1 and AI2 (|AI1-AI2|).
SuM Sum of values read on inputs AI1 and AI2 (AI1+AI2).
c.2.S Pv Command 2 setpoint
ou.Pe.2 Percentage of command output 2
AMPer. Ampere from current transformer
279
tMo.d. Timeout Display
Determines the display timeout
diS a b. Disabled. Display always ON (Default)
1S S 15 seconds
1 Min 1 minute
5 Min 5 minutes
10 Min 10 minutes
3 0 Min 30 minutes
1 h 1 hour
280
tMo .S. Timeout Selection
Selects which display is switched off when Display Timout expires
d is p.1 Display 1
d is p. 2 Display 2 (Default)
d s p. 1. 2 Display 1 and 2
d.1.2.Ld. Display 1, 2 and led
281
u.M.P. c. User Menu Pre-Programmed Cycle
Allows to modify rising/falling gradient and rentention time form the user menu, in pre-pro-
grammed cycle functioning. To access parameter modification, press SET.
dis a b. Disabled (Default)
ris. G r. Only rising gradient
m a . ti. Only retention time
ri. G. m.t. Rising gradient and retention time
faL.Gr Only falling gradient
ri.Fa.G. Rising and falling gradient
fa.G.m.t. Falling gradient and retention time
r. f. G . m . t. Rising gradient, retention time and falling gradient
