User manual - ATR244 - 39
GROUP G -
AL. 1
- ALARM 1
123 A L .1 . f . Alarm 1 Function
Alarm 1 selection.
diS a b. Disabled (Default)
A b . u p. A . Absolute Upper Activation. Absolute referred to the process, active over
Ab.Lo.a. Absolute Lower Activation. Absolute referred to the process, active under
bAnd Band alarm (command setpoint ± alarm setpoint)
u p. d e v. Upper Deviation alarm
L o . d e v. Lower Deviation alarm
Ab.c.u.A. Absolute Command Upper Activation. Absolute alarm referred to the command
setpoint, active over
A b.c.L. A. Absolute Command Lower Activation. Absolute alarm referred to the command
setpoint, active under
run Status alarm (active in RUN/START)
cooL Cold actuator auxiliary (Cold action in double loop)
P r b . e r. Probe error. Alarm active in case of sensor ropture.
t M r.1 Related to timer 1
t M r. 2 Related to timer 2
t M r.1.2 Related to both timers
rEM. Remote. The alarm is enabled by the word 1235
d.i. 1 Digital Input 1. Active when digital input 1 is active.
d.i. 2 Digital Input 2. Active when digital input 2 is active.
d.i. 3 Digital Input 3. Active when digital input 3 is active.
d.i. 4 Digital Input 4. Active when digital input 4 is active.
H.b.A. Heater Break Alarm and Overcurrent Alarm
124
A .1 . P r. Alarm 1 Process (only on ATR-ABC-T)
Selects the size related to alarm 1.
A.i n .1 Value read on input AI1. (Default)
A.i n . 2 Value read on input AI2.
MEAn Arithmetic average of the value read on inputs AI1 and AI2 [(AI1+AI2)/2].
d i F F. Difference of the values read on inputs AI1 and AI2 (AI1-AI2).
A b . d i f. Module of the difference of the values read on inputs AI1 and AI2(|AI1-AI2|).
SuM Sum of values read on inputs AI1 and AI2 (AI1+AI2).
125
A.I. r. c. Alarm 1 Reference Command
Selects alarm 1 reference command
cmd. 1 Alarm referred to command 1. (Default)
cmd. 2 Alarm referred to command 2.
126
A . I. 5 . o . Alarm 1 State Output
Alarm 1 output contact and intervention type.
n.o. S t. (N.O. Start) Normally open, active at start (Default)
n.c. S t. (N.C. Start) Normally closed, active at start
n.o. tH. (N.O. Threshold) Normally open, active on reaching alarm
2 p. 65
n.c. t H. (N.C. Threshold) Normally closed, active on reaching alarm
2 p. 65
127 rEs . Reserved
Reserved parameter.
128 a .1 . H y . Alarm 1 Hysteresis
Alarm 1 hysteresis
-9999..+9999 [digit
1 p. 65
] (degrees for temp. sensors). Default 0.5.
