Pixsys ATR244 User Manual

28 - ATR244 - User manual
GROUP B -
A.i n .2
- Analogue input 2
18 SEN.2 Sensor AI2
Analogue input configuration / sensor AI2 selection
diS a b. Disabled Disabled. (Default)
tc. k Tc-K -260 °C..1360 °C.
tc. s Tc-S -40 °C..1760 °C
tc. r Tc-R -40 °C..1760 °C
tc. J Tc-J -200 °C..1200 °C
Tc. T Tc-T -260 °C..400 °C
tc. E Tc-E -260 °C..980 °C
tc. N Tc-N -260 °C..1280 °C
tc. b Tc-B 100 °C..1820 °C
Pt10 0 Pt100 -200 °C..600 °C
ni10 0 Ni100 -60 °C..180 °C
ntc NTC 10K -40 °C..125 °C
Ptc PTC 1K -50 °C..150 °C
Pt500 Pt500 -200 °C..600 °C
Pt1k Pt1000 -200 °C..600 °C
0-1 0..1 V
0-5 0..5 V
0-10 0..10 V
0-20 0..20 mA
4-20 4..20 mA
0-60 0..60 mV
Po t. PPotentiometer (set the value on parameter 23)
19
d .P. 2 Decimal Point 2
Select number of displayed decimal points for AI 2
0 Default
0.0 1 decimal
0.0 0 2 decimals
0.000 3 decimals
20
rEs . Reserved
Reserved parameter.
21
L.L.i .2 Lower Linear Input AI2
AI2 lower limit only for linear signals. Ex.: with input 4..20 mA this parameter takes value associated
to 4 mA. The value may be greater than the one entered on the next parameter.
-9999..+30000 [digit
1 p. 65
] Default: 0.
22
u.L.i.2 Upper Linear Input AI2
AI2 upper limit only for linear signals Ex: with input 4..20 mA this parameter takes value associated
to 20 mA.The value may be lower than the one entered on the previous parameter..
-9999..+30000 [digit
1 p. 65
] Default:1000
23
P. v A . 2 Potentiometer Value AI2
Selects the value of the potentiometer connected on AI2
1..150 kohm. Default: 10kohm
24
i.o.L.2 Linear Input over Limits AI2
If AI2 is a linear input, allows to the process to overpass the limits (Par. 18 and 19).
diS a b. Disabled (Default)
Enab. Enabled
