User manual - ATR244 - 29
25 o . cA.2 Offset Calibration AI2
AI2 Offset calibration. Value added/subtracted to the process value (ex: usually correcting the
ambient temperature value).
-9999..+9999 [digit
1 p. 65
] (degrees.tenths for temperature sensors). Default 0.
26
G. ca .2 Gain Calibration AI2
Value multiplied to the process value to calibrate the working point. Ex: to correct the range from
0..1000°C showing 0..1010°C, set the parameter to -1.0
-100.0%...+100.0%, Default: 0.0.
27
Lt c.2 Latch-On AI2
Automatic setting of limits for AI2 linear input
diS a b. Disabled (Default)
Stnrd Standard
v. 0 .s t o . Virtual Zero Stored
v. 0 . t. o n Virtual Zero at start
28
c.FL.2 Conversion Filter AI2
ADC Filter: Number of sensor readings to calculate mean that defi nes
process value.
NB: When readings increase, control loop speed slows down.
1...15. (Default: 10)
29
c.Fr.2 Conversion Frequency AI2
Sampling frequency of digital / analogue converter for AI2.
Increasing the conversion speed will slow down reading stability
(example: for fast transients, as the pressure, it is advisable to increase
sampling frequency).
4.17. Hz 4.17 Hz (Min. conversion speed)
6.25Hz 6.25 Hz
8.33 Hz 8.33 Hz
10.0Hz 10.0 Hz
12.5 Hz 12.5 Hz
1 6 .7 H z 16.7 Hz (Default) Ideal for filtering noises 50 / 60 Hz
19.6Hz 19.6 Hz
33.2Hz 33.2 Hz
39.0 Hz 39.0 Hz
50.0 Hz 50.0 Hz
6 2. 0 Hz 62.0 Hz
123 Hz 123 Hz
242Hz 242 Hz
470 Hz 470 Hz (Max. speed conversion)
30÷34 Reserved Parameters - Group B
Reserved parameters - Group B
