Pixsys ATR244 User Manual

User manual - ATR244 - 67
56 rEM.S. Remote Setpoint (only on ATR244-23ABC-T) 32
57
Ac. t.2 Action type 2 32
58
c.HY.2 Command Hysteresis 2 32
59
L.L.S.2 Lower Limit Setpoint 2 32
60
U.L.S.2 Upper Limit Setpoint 2 33
61
c. re.2 Command Reset 2 33
62
c.S. e.2 Command State Error 2 33
63
c.Ld.2 Command Led 2 33
64
c. de.2 Command Delay 2 33
65
c.S. p.2. Command Setpoint Protection 2 33
66
vA. t.2 Valve Time 2 33
67
a.ma.2 Automatic / Manual 2 34
68÷72 Reserved Parameters - Group D 34
GROUP E -
r e G .1
- Autotuning and PID 1
73
t u n .1 Tune 1 34
74
s.d.t.1 Setpoint Deviation Tune 1 34
75
p. b. 1 Proportional Band 1 34
76
i . t. 1 Integral Time 1 34
77
d . t. 1 Derivative Time 1 34
78
d . b . 1 Dead Band 1 34
79
p.b.c.1 Proportional Band Centered 1 34
80
o.o.s.1 Off Over Setpoint 1 34
81
o.d.t.1 Off Deviation Threshold 1 35
82
c. t. 1 Cycle Time 1 35
83
c o . F.1 Cooling Fluid 1 35
84
P. b . M .1 Proportional Band Multiplier 1 35
85
o.d.b.1 Overlap / Dead Band 1 35
86
c. c. t.1 Cooling Cycle Time 1 35
87
L.L. P.1 Lower Limit Output Percentage 1 35
88
U . L . p .1 Upper Limit Output Percentage 1 35
89
m . G . t .1 Max Gap Tune 1 35
90
m n . p .1 Minimum Proportional Band 1 35
91
m a . p .1 Maximum Proportional Band 1 35
92
mn.i.1 Minimum Integral Time 1 36
93
o . c . L.1 Overshoot Control Level 1 36
94÷97 Reserved Parameters - Group E 36
GROUP F -
reG.2
- Autotuning and PID 2
98
tun.2 Tune 2 36
99
s.d.t.2 Setpoint Deviation Tune 2 36
100
p. b. 2 Proportional Band 2 36
101
i . t. 2 Integral Time 2 36
102
d . t. 2 Derivative Time 2 36
103
d . b . 2 Dead Band 2 36
104
p.b.c.2 Proportional Band Centered 2 37
105
o.o.s.2 Off Over Setpoint 2 37
106
o.d.t.2 Off Deviation Threshold 2 37
107
c. t. 2 Cycle Time 2 37
108
co.F.2 Cooling Fluid 2 37
109
P. b .M.2 Proportional Band Multiplier 2 37

Pixsys ATR244 Specifications

General

Brand	Pixsys
Model	ATR244
Category	Controller
Language	English
