68 - ATR244 - User manual
110
o.d.b.2
Overlap / Dead Band 2 37
111
c. c. t.2
Cooling Cycle Time 2 37
112
L.L.P.2
Lower Limit Output Percentage 2 37
113
U.L. p.2
Upper Limit Output Percentage 2 37
114
m.G.t.2
Max Gap Tune 2 38
115
m n .p.2
Minimum Proportional Band 2 38
116
m a .p.2
Maximum Proportional Band 2 38
117
mn.i.2
Minimum Integral Time 2 38
118
o.c.L.2
Overshoot Control Level 2 38
119÷122 Reserved Parameters - Group F 38
GROUP G -
AL. 1
- ALARM 1
123
A L .1 . f .
Alarm 1 Function 39
124
A .1 . P r.
Alarm 1 Process (only on ATR244-23ABC-T) 39
125
A.I. r. c.
Alarm 1 Reference Command 39
126
A . I. 5 . o .
Alarm 1 State Output 39
127
rEs .
Reserved 39
128
a .1 . H y .
Alarm 1 Hysteresis 39
129
A.1.L.L.
Alarm 1 Lower Limit 40
130
A .1 . u . L .
Alarm 1 Upper Limit 40
131
a .1 . r e .
Alarm 1 Reset 40
132
A .1 . S . e .
Alarm 1 State Error 40
133
A .1 . L d .
Alarm 1 Led 40
134
a .1 . d e .
Alarm 1 Delay 40
135
A .1 . S . p .
Alarm 1 Setpoint Protection 40
136
A .1 . L b .
Alarm 1 Label 40
137÷140 Reserved Parameters - Group G 40
GRUPPO H -
AL. 2
- Alarm 2
141
AL.2. f.
Alarm 2 Function 41
142
A.2.Pr.
Alarm 2 Process (only on ATR244-23ABC-T) 41
143
A.2. r. c.
Alarm 2 Reference Command 41
144
A.2.5. o .
Alarm 2 State Output 41
145
rEs .
Reserved 41
146
a.2.Hy.
Alarm 2 Hysteresis 41
147
A.2.L. L.
Alarm 2 Lower Limit 42
148
A.2. u .L.
Alarm 2 Upper Limit 42
149
a .2. re.
Alarm 2 Reset 42
150
A.2.S. e.
Alarm 2 State Error 42
151
A.2.Ld.
Alarm 2 Led 42
152
a .2. d e.
Alarm 2 Delay 42
153
A.2.S. p.
Alarm 2 Setpoint Protection 42
154
A.2.Lb.
Alarm 2 Label 42
155÷158 Reserved Parameters - Group H 42
GROUP I -
AL. 3
- Alarm 3
159
AL.3. f.
Alarm 3 Function 43
160
A.3. P r.
Alarm 3 Process (only on ATR244-23ABC-T) 43
161
A.3. r. c.
Alarm 3 Reference Command 43
162
A.3.5. o .
Alarm 3 State Output 43
163
A.3.o.t.
Alarm 3 Output Type 43
