7 Planmeca ProMax 3D Plus and 3D Mid programs
7.1 3D Dental
NOTE
The values in parentheses represent the child size volumes.
Program Planmeca ProMax 3D Plus Planmeca ProMax 3D Mid
Tooth Ø40 x H50 mm (Ø34 x H42 mm)
Ø40 x H80 mm (Ø34 x H68 mm)
Ø40 x H50 mm (Ø34 x H42 mm)
Ø40 x H80 mm (Ø34 x H68 mm)
Teeth Ø80 x H50 mm (Ø68 x H42 mm)
Ø80 x H80 mm (Ø68 x H68 mm)
Ø100 x H60 mm (Ø85 x H50 mm)
Ø100 x H100 mm (Ø85 x H85 mm)
Ø80 x H50 mm (Ø68 x H42 mm)
Ø80 x H80 mm (Ø68 x H68 mm)
Ø100 x H60 mm (Ø85 x H50 mm)
Ø100 x H100 mm (Ø85 x H85 mm)
Jaw Ø160 x H60 mm (Ø160 x H60 mm)
Ø160 x H100 mm (Ø160 x H100 mm)
Ø200 x H60 mm (Ø200 x H60 mm)
Ø200 x H100 mm (Ø200 x H100 mm)
Ø160 x H60 mm (Ø160 x H60 mm)
Ø160 x H100 mm (Ø160 x H100 mm)
Ø200 x H60 mm (Ø200 x H60 mm)
Ø200 x H100 mm (Ø200 x H100 mm)
Face
Not available
Ø160 x 90 mm (Ø160 x 90 mm)
Ø160 x 160 mm (Ø160 x 160 mm)
Ø200 x H100 mm (Ø200 x H100 mm)
Ø200 x H170* mm (Ø200 x H170* mm)
* = Two vertical image volumes
7.2 3D Ear Nose Throat
NOTE
The values in parentheses represent the child size volumes.
Program Planmeca ProMax 3D Plus Planmeca ProMax 3D Mid
Nose Ø80 x H80 mm (Ø68 x H68 mm) Ø80 x H80 mm (Ø68 x H68 mm)
Sinus Ø100 x H100 mm (Ø100 x H100 mm)
Ø160 x H100 mm (Ø160 x H100 mm)
Ø200 x H100 mm (Ø200 x H100 mm)
Ø100 x H80 mm (Ø100 x H80 mm)
Ø100 x H100 mm (Ø100 x H100 mm)
Ø100 x H140 mm (Ø100 x H140 mm)
Ø160 x H80 mm (Ø160 x H80 mm)
Ø160 x H100 mm (Ø160 x H100 mm)
Ø160 x H140 mm (Ø160 x H140 mm)
Ø200 x H80 mm (Ø200 x H80 mm)
Ø200 x H100 mm (Ø200 x H100 mm)
Ø200 x H140 mm (Ø200 x H140 mm)
Airways Ø80 x H80 mm (Ø68 x H68 mm) Ø80 x H80 mm (Ø68 x H68 mm)
Middle ear Ø40 x H50 mm (Ø34 x H42 mm)
Ø80 x H80 mm (Ø68 x H68 mm)
Ø40 x H50 mm (Ø34 x H42 mm)
Ø80 x H80 mm (Ø68 x H68 mm)
