17 Technical data for Planmeca ProMax product family
Classification
Medical Device Directive 93/42/EEC (Class IIb)
RoHS 2011/65/EU
IEC 60601-1 Class I, type B
CISPR 11 Class B
IP Classification IP20
Applied parts (according to IEC 60601-1: 2012)
Patient supports As shown in section Patient supports in User
Manuals
Patient handles
Generator (according to IEC 60601-2-7: 1998)
Resonant-mode, DSP-controlled, 80 - 160 kHz
X-ray tube
2D / 3D s / 3D Classic D-054SB
3D Plus / 3D Mid D-054SB, D-059SBR or SXR 130-10-0.5 SC
3D Max D-067SB, D-059SBR or SXR 130-10-0.5 SC
Focal spot size (according to IEC 60336: 2005)
2D / 3D s / 3D Classic / 3D Plus / 3D Mid with X-
ray tube D-054SB
0.5 x 0.5 mm
3D Plus / 3D Mid / 3D Max with X-ray tube
D-059SBR or SXR 130-10-0.5 SC
0.5 x 0.5 mm
3D Max with X-ray tube D-067SB 0.6 x 0.6 mm
Filtration
Pan / ceph Total 2.5 mm Al
3D Total 2.5 mm Al + 0.5 mm Cu
SmartPan • 3D s / 3D Classic / 3D Plus / 3D Mid: total
2.5 mm Al
• 3D Max: total 2.5 mm Al + 0.5 mm Cu
Tube housing front cover quality equivalent
filtration (not included in the specified total
filtration)
0.3 mm Al @ 70 kV / HVL 2.6 mm Al
Anode voltage
Pan / SmartPan 60 - 84 kV ±5%
Ceph 60 - 84 kV ±5%
3D s / 3D Classic / 3D Plus or 3D Mid with X-ray
tube D-054SB
60 - 90 kV ±5%
3D Max with X-ray tube D-067SB 60 - 96 kV ±5%
3D Plus / 3D Mid / 3D Max with X-ray tube
D-059SBR or SXR 130-10-0.5 SC
60 - 120 kV ±5%
Anode current
Pan 1 - 16 mA ±10%
17 Technical data for Planmeca ProMax product family
User's manual Planmeca ProMax 95
