Scan Engine
1D engine: N4313
2D engine : N560x
Keypad Numeric , Qwerty
Audio Built-in microphone and speaker
I/O High speed USB 2.0 from cradle (or I/O cable)
Battery Li-ion battery 3.7V / 4000 mAh / 14.8 Wh
Expected Hours of
Operation
8.5+ hours (with scan and continuously transmitting if using new standard Li-ion battery)
Charging 5V input through MicroUSB port.
Expected Charge Time Capacity: 4000mAh – approx. 5 hours
Charging Peripherals
MicroUSB Adaptor
Single Slot cradle–single-bay terminal charge/communicate
Single Ethernet cradle–single-bay terminal charge/communication base
(Via Ethernet connection)
Quad Battery Charger
WPAN Bluetooth Class II (10 m) v2.1 Enhanced Data Rate (EDR) with internal antenna.
WLAN Dual Mode 802.11 b/g/n (11 Mbps/54 Mbps) with internal antenna
WLAN Security
Wi-Fi Certified, 802.1X, WPA2, EAP, WEP, LEAP, TKIP, MSD, EAP-TLS, EAP-TTLS,
WPAPSK, PEAP, CCXv4
WWAN
GSM: Quad band, 850/900/1800/1900MHz
UMTS/HSPA+: Five band, 800/850/900/1900/2100MHz
GPS Assisted GPS
Operating
Temperature
-20° to 55°C
Charging Temperature
0~45℃ (±3℃))
Storage Temperature -25ºC to 70ºC
Humidity 95% humidity, non-condensing
Construction
High impact resistant PC/ABS housings
Magnesium alloy internal chassis with component shock mounts
Drop
1.22m multiple drops to concrete, MIL-STD-810G, Method 516.6, Procedure
Tumble 3.3 ft (1.0m) tumbles (500 drops)
ESD
Air: ± 15kV
Direct: ± 8kV
Environmental Independently certified to meet IP65 standards for moisture and particle resistance
Dimensions H; 157.4mm x W; 74.2mm x L; 25.8mm(top)
Weight
1) 1D ; 330g (239g with battery)
2) 2D ; 330g (239g with battery)
