Input (Universal)
(from the power source)
AC 100–240 Vac.
50/60Hz 0.9A
Included with Charger
Output
(to the cradle)
DC 5V , 4A
Charging
Standard Charge
Main battery: Standard Capacity:
4000mAh (60-BTSC) – Approx. 5hours
Status LED
Green: charged
Red: charging
Agency Approvals
Power Supply
UL listed
TUV licensed
Power Supply compliant to FCC part 15, Class B
Charging
CE Marking (EMC)
CISPR Pub 22
Fire Retardant
UL
94-
HB
78
