Polycom realpresence group series

System Back Panel Views
Polycom, Inc. 230
16 Audio/Video >
Monitors > Monitor
1
Video Output 1
Audio Output 1
HDMI Output for Monitor 1
Audio Mix Routed to the Output:
System tones and sound effects +
Audio from the far site +
Audio input from audio inputs 3 and 4 when
associated video is selected
17 Audio/Video >
Monitors > Monitor
2
Video Output 2 VGA Output for Monitor 2
18 Audio/Video >
Monitors > Monitor
2
Video Output 2 HDMI Output for Monitor 2
19 Audio/Video >
Monitors > Monitor
3
Video Output 3 VGA Output for Monitor 3
20 Audio/Video >
Monitors > Monitor
3
Video Output 3 HDMI Output for Monitor 3
Note: Use either the HDMI or VGA for video outputs 1, 2, and 3, but not both.
21 General Settings >
Serial Ports
Serial Port RS-232 Serial port
22 N/A USB
Connectors
USB 3.0 USB for Software Update, remote control
battery charging
23 Network > LAN
Properties > LAN
Options
PC LAN Port Ethernet Ethernet switch port
24 Network > LAN
Properties
LAN Port Ethernet Connectivity for IP calls, People+Content IP,
and the system web interface
Ref.
Number
Location in
Web Interface:
Admin Settings > Input/ Output
Supported
Formats Description
