POWER ELECTRONICS
DESCRIPTION OF PROGRAMMING PARAMETERS
119
Screen
Description
Default
value
Range
Function
Set
on
RUN
bA.6
Alternative
torque
reference
LOCAL
Note: comes from the previous page.
OPT.
DESCR.
FUNCTION
6
MODBUS
The reference will be
introduced through
Modbus.
8
COMMS
The reference will be
introduced through
communications.
9
PLC
The common area can
be linked with user
sequence output and
can be used as
command.
12
PULSE
Reference will be
introduced through the
Pulse input.
YES
bA.7
V/F Pattern
Linear
0 to 3
Set the alternative acceleration ramp.
OPT.
DESCR.
FUNCTION
0
Linear
Output voltage increases
and decreases at constant
rate proportional to
voltage/frequency (V/F)
relation. Used to achieve a
constant torque load
regardless the frequency.
1
Square
Output voltage increases
quadratically with a
proportion of 1.5.
2
V/F Us
Define a customized V/F
pattern.
3
Square2
Output voltage increases
quadratically with a
proportion of 2.
NO
