Power Electronics SD300 Series User Manual

POWER ELECTRONICS
SD300
DESCRIPTION OF PROGRAMMING PARAMETERS
193
Screen
Description
Default
value
Range
Function
Set on
RUN
AP.38
Sleep mode
activation
speed
0.00Hz
0.00Hz
to dr.20
Set the speed under which if a time period
greater than the one defined in parameter
AP.37, the drive will stop operating and
enter in sleep mode.
YES
AP.39
Awakening
level
+35%
0 to
100%
Set the resuming PID control level after a
suspension period (sleep mode).
YES
AP.40
PID WakeUp
mode
Below
Below
Above
Beyond
Set PID wake-up mode, according to the
following table:
OPT.
DESCR.
FUNCTION
0
Below
The PID operation starts
when the frequency is
lower than the value set in
AP.39.
1
Above
The PID operation starts
when the frequency is
higher than the value set in
AP.39.
2
Beyond
The PID operation starts
when the difference
between the reference
value and the feedback
variable is greater than the
value set in (AP.39).
YES
AP.42
PID unit
0%
0 to 12
Set PID controller unit, according to the
following table:
OPT.
DESCR.
OPT.
DESCR.
0
%
7
V
1
Bar
8
I
2
mBar
9
kW
3
Pa
10
HP
4
kPa
11
°C
5
Hz
12
ºF
6
rpm
YES
AP.43
PID unit gain
100.00%
0.00 to
300.00%
Allows setting the PID unit gain.
YES
