Power Electronics SD300 Series - Page 289

POWER ELECTRONICS
SD300
ACCESSORIES
287
Frames 4, 5 & 6:
Frames 4, 5 & 6 flange option kit dimensions
Model
W
H
D1
D2
A1
A2
B1
B2
B3
Ø
Weight*
mm
(in)
mm
(in)
mm
(in)
mm
(in)
mm
(in)
mm
(in)
mm
(in)
mm
(in)
mm
(in)
mm
(in)
kg
(lb)
SD303022,
SD304022
SD301642F,
SD302342F
206
(8.11)
264.5
(10.41)
140
(5.51)
55.1
(2.17)
186
(7.32)
178
(7.01)
251.5
(9.90)
235
(9.25)
8.4
(0.33)
5
(0.20)
3.7
(8.16)
