Power Electronics SD300 Series User Manual

SD300
POWER ELECTRONICS
288
ACCESSORIES
Model
W
H
D1
D2
A1
A2
B1
B2
B3
Ø
Weight*
mm
(in)
mm
(in)
mm
(in)
mm
(in)
mm
(in)
mm
(in)
mm
(in)
mm
(in)
mm
(in)
mm
(in)
kg
(lb)
SD305622,
SD303042F
SD303842F
225.2
(8.87)
322.7
(12.71)
163
(6.42)
72.1
(2.84)
205.2
(8.09
197.5
(7.78)
309.7
(12.19)
292.5
(11.52)
9.3
(0.37)
5
(0.20)
5.15
(11.35)
SD306922,
SD304442F
SD305842F
267
(10.51)
384.5
(15.14)
187
(7.36)
93.6
(3.69)
247
(9.72)
239
(9.41)
371.5
(14.63)
352
(13.86)
9.5
(0.37)
6
(0.24)
5.4
(11.91)
*Total weight of the drive with the flange installed
Drive + Flange Mounting
The SD300 variable speed drives are designed to be mounted on a wall
or inside a panel.
The inverter can become very hot during operation. Install the inverter on
a surface that is fire-resistant or flame-retardant and with sufficient
clearance around the inverter to allow air to circulate.
Make sure to follow the mounting and clearance recommendations in
sections Drive Mounting and Clearances respectively.
The number of required screws for fixing the drive + flange varies
depending the frame and is shown in the table below. Please refer to
section “DIMENSIONS” to verify the frame and exact measures of your
SD300 drive.
Frame
Fixing screws
(number * metric)
1N, 2N, 1F
2*M3
3N, 4N, 5N, 2F, 3F
2*M4
4, 5
4*M4
6
4*M5
