CONTROL CONNECTION
77
The following table contains the control terminals description:
SIGNAL
PIN
DESCRIPTION
DIGITAL INPUTS
P1
Configurable multi- function Input. Default value: FX.
P2
Configurable multi- function Input. Default value: RX.
P3
Configurable multi- function Input. Default value: BX.
P4
Configurable multi- function Input. Default value: RST.
P5
Configurable multi- function Input. Default value: Spd-L.
P6
[1]
Configurable multi- function Input. Default value: Spd-M.
P7
[1]
Configurable multi- function Input. Default value: Spd-H.
CM
Common terminal for analog and digital terminal inputs and
outputs.
DIGITAL OUTPUTS
Q1
Multi-function Terminal (Open-collector). 26VDC, ≤100mA.
Default value: Run.
EG
Common ground contact for an open collector (with external
power source).
24
External 24V power source. 150mA maximum output current.
A1
Fault signal output. Sends out alarm signals when the
inverter safety features are activated (AC 250V <1A, DC 30V
< 1A).
- Fault condition: A1 and C1 contacts are connected (B1
and C1 open connection).
- Normal operation: B1 and C1 contacts are connected
(A1 and C1 open connection).
C1
B1
ANALOGUE
INPUTS
VR
Power terminal used to setup or modify a frequency
reference via analog voltage or current input.
Max output V/I: 12V / 100mA, Potentiometer 1~5kΩ.
V1
Setup or modify a frequency reference via analog voltage
input terminal.
- Unipolar: 0 ~ 10V (max12V)
- Bipolar: -10 ~ 10V (max ±12V)
[
1
]Only available in IP20 drives.
