Installation and Operation Manual Page 52 of 104
(PVI-3.8/4.6-I-OUTD-US Rev.: 1.1)
To insert the new battery into the battery holder the battery needs to be slid at a 30°
angle as shown in Fig. 20, and when pushed in on insertion it should seat into the
correct position within the holder.
Fig. 20 - Lithium Battery Replacement
WARNING: The replacement of this battery should be performed only by
trained personnel.
After battery replacement is completed, reinstall and secure the front panel of the
inverter and perform the START-UP procedure in section 4.
It is necessary to set Date and Time from display menu.
Battery
