Power One AURORA - Address; Display Set

Installation and Operation Manual Page 79 of 104
(PVI-3.8/4.6-I-OUTD-US Rev.: 1.1)
5.4.6.1 Address
This function is used to set addresses for communication of the single inverters
connected in the system on an RS485 line. You can assign numbers from 2 to 64.
Press the UP and DOWN keys to scroll numbers.
If you do not want to manually set the address of each inverter, select the AUTO
function and they will be distributed automatically.
5.4.6.2 Display Set
This function is used to set the display features:
1) Light: Display light setting:
- Use the MODE key to set the display backlighting.
Select the Mode item with the arrow, and press ENTER to open the relevant submenu.
The next screen is:
ON: Light always on
OFF: Light always off
AUTO: Automatic light setting. It turns on every time a key is pressed and stays on for
30 seconds then gradually turns off.
- Use the INTENSITY key to set the intensity of backlighting from 1 to 9
ON
OFF
Auto
Mode
Intensity
Light
Contrast
Buzzer
New Address
Auto
New Address
62
AUTO
2
3
…..
…..
63
64
AUTO
