Installation and Operation Manual Page 81 of 104
(PVI-3.8/4.6-I-OUTD-US Rev.: 1.1)
5.4.6.6 Time
If necessary, the time and date settings can be adjusted from this section.
5.4.6.7 Language
It is possible to set the national language or English.
5.4.6.8 START-UP Voltage
The start-up voltage for both input channels can be set according to the available
photovoltaic system. The voltage can range from 120V to 350V. The default setting
for Aurora is 200V. This parameter can be changed by means of the display keys.
When the independent input mode is selected it’s possible to set different start-up
voltage for channel 1 and channel 2.
5.4.6.9 Alarm
The inverter features an alarm function that opens or closes a relay contact (available
both as contact normally open – N.O. – and as contact normally closed – N.C.). The
contacts can be accessed through the front panel as shown in Fig. 25. This contact can
be used for instance to activate a siren or a visual alarm: In any case the contact's
voltage/current rating of 230V/1A must not be exceeded.
This function can activate 2 different alarm modes. Press the ENTER key to open the
relevant submenu:
An arrow on left side of the display highlights your current selection. When the chosen
item is selected, press ENTER to confirm activation of the chosen mode.
Production
