Power One AURORA - Selecting AC and DC Wiring

Installation and Operation Manual Page 38 of 104
(PVI-3.8/4.6-I-OUTD-US Rev.: 1.1)
3.3.4.1 AC and DC wire selection
The following tables help installers to select the proper cable size and tighten
correctly to the screw terminals
PVI-3.8-I-OUTD
AWG 167°F
(75°C)
AWG 194°F
(90°C)
PVI-3.8-I-OUTD-S-
US-xx
8-4 10-4 DC input wiring
PVI-3.8-I-OUTD-US-
xx
8-6 10-6
Ground PVI-3.8-I-OUTD 4 4
PVI-3.8-I-OUTD-S-
US-xx
8-4 10-4 AC output wiring
PVI-3.8-I-OUTD-US-
xx
8-6 10-6
Main ground PVI-3.8-I-OUTD 6 6
PVI-4.6-I-OUTD
AWG 167°F
(75°C)
AWG 194°F
(90°C)
PVI-4.6-I-OUTD-S-
US-xx
8-4 10-4 DC input wiring
PVI-4.6-I-OUTD-US-
xx
8-6 10-6
Ground PVI-4.6-I-OUTD 4 4
PVI-4.6-I-OUTD-S-
US-xx
8-4 8-4 AC output wiring
PVI-4.6-I-OUTD-US-
xx
8-6 8-6
Main ground PVI-4.6-I-OUTD 6 6
