Powtran PI9000 series User Manual

Chapter 5 Function parameter
98
F1.05
DI6 terminal function
selection
0 to 51
13
F1.06
DI7 terminal function
selection
0 to 51
0
F1.07
DI8 terminal function
selection
0 to 51
F1.08
Undefined
F1.09
Undefined
These parameters are used to set the digital multi-function input terminal, the optional
functions are shown in the following table:
Set
value
Function
Description
0
No function
The terminal for not use can be set to "no
function" to prevent accidental operation.
1
Forward run (FWD)
External terminals are used to control the
FWD/REV run mode of inverter.
2
Reverse run (REV)
3
Three-wire operation
control
This terminal is used to determine the inverter's
three-wire control mode. For details, please refer to
the instructions of function code F1.10 ("terminal
command mode).
4
Forward JOG(FJOG)
FJOG means Forward JOG running, RJOG means
Reverse JOG running. For Jog running frequency
and Jog Ac/deceleration time, please refer to the
description of the function code F7.00, F7.01,
F7.02.
5
Reverse JOG(RJOG)
6
Terminal UP
Modify frequency increment/decrement command
when the frequency is referenced by external
terminal. Adjust up/down the set frequency when
the digital setting is selected as the frequency
source.
7
Terminal DOWN
8
Free stop
The inverter output is blocked, at the time, the
parking process of motor is not controlled by the
inverter. This way is same as the principle of free
stop described in F3.07.
9
Fault reset (RESET)
The function make use of terminal for fault reset.
It has same function with RESET key on the
keyboard. This function can be used to realize
remote fault reset.
10
Run pausing
The inverter slows down and stops, but all
operating parameters are memorized. Such as
