Powtran PI9000 series User Manual

Chapter 10 Options
207
5.5
30
500
7.5
20
780
380V
0.75
750
120
1.5
400
300
2.2
250
300
4
150
500
5.5
100
500
7.5
75
780
11
50
1000
15
40
1500
10-7.Output EMI filter
It is used to inhibit noise interference and leakage current generated in the inverter
output side.
10-8.AC output reactor
When the connection wire from the inverter to the motor is longer (over 20 meters),
it is used to inhibit overcurrent caused due to the distributed capacitance. Meanwhile, it
can also inhibit the radio interference of the inverter.
10-9.Input filter
10-9-1.Input filter(380V)
No.
Model
Voltage(V)
Power(KW)
Current(A)
Net
weight(kg)
Dimensions
L/W/H(mm)
Installation
size
W1/H1(m
m)
1
NFI-
005
380
0.75 to 1.5
5
0.7
130/105/44
51/95
2
NFI-
010
380
2.2 to 4
10
1.3
202/86/58
184/60
3
NFI-
020
380
5.5 to 7.5
20
2.5
261/100/90
243/70
4
NFI-
036
380
11 to 15
36
2.7
261/100/90
243/70
5
NFI-
050
380
18.5 to 22
50
3.5
261/100/90
243/70
6
NFI-
065
380
30
65
4.5
240/190/90
180/175
7
NFI-
080
380
37
80
6.6
390/200/90
260/185
