Powtran PI9000 series User Manual

Appendix V
244
第
十
章
Appendix V Profibus-DP communication card use description
V-1.Outline
9KDP1 meet the international standard PROFIBUS fieldbus, powtran
technology 9K series inverter use it together to achieve the drive to become a
part of fieldbus complete control of real fieldbus. Before using this product,
please carefully read this manual
V-2.Terminal function
V-2-1.DIP switch description
DIP switch
position No.
Function
instruction
1,2
DP Card and the
drive baud rate
selection
Bit 1
Bit 2
Baud Rate
OFF
OFF
115.2K
OFF
ON
208.3K
ON
OFF
256K
ON
ON
512K
3-8
Profibus-DP
Communication
from the station
address
6 Binary Consisting of 64-bit binary address,
more than 64 outside the address can be set
only by function code. The following lists
some slave address and switch settings
Address switch settings
0 00 0000
7 00 0111
20 01 0100
Table 2.1 DIP Switch Functions
V-2-2.Terminal Function
1)external communication terminal J4-6 PIN
Terminal NO
Mark
Function
1
GND
Isolated 5V power ground
2
RTS
Request to send signal
3
TR-
Negative data line
4
TR+
Positive data line
5
+5V
Isolated 5V power supply
6
E
Ground terminals
Table 2.2 External Communication Terminal Function
2)PC communication interface SW1-8 PIN
Terminal NO
Terminal identification
Function
1
BOOT0
ARM boot select
2
GND
Digital Ground
3
VCC
Digital Power
4
Reserve
Reserve
5
PC232T
PC 232 communication transmitting
end
