Chapter 5 Function parameter
49
No.
Code
Parameter name
Setting range
Factory
setting
Change
Reference
page
deceleration A
2: S curve
acceleration and
deceleration B
151.
F3.14
Proportion of S
curve start-section
0.0% to (100.0% to
F3.15)
30
.
0%
120
152.
F3.15
Proportion of S
curve end-section
0.0% to (100.0% to
F3.14)
30
.
0%
120
5-1-6.F4 Group - V/F control parameters
No.
Code
Parameter name
Setting range
Factory
setting
Change
Reference
page
153.
F4.00
V/F curve setting
0 to11
0
121
154.
F4.01
Torque boost
0.0%(Automatic
torque boost)
0.1 to 30%
-
121
155.
F4.02
Torque boost cut-
off frequency
0.00Hz to
F0.19(maximum
frequency)
15
.
00Hz
122
156.
F4.03
Multipoint V/F
frequency point 1
0.00Hz to F4.05
0.00Hz
122
157.
F4.04
Multipoint V/F
voltage point 1
0.0% to 100.0%
0.0%
122
158.
F4.05
Multipoint V/F
frequency point 2
F4.03 to F4.07
0.00Hz
122
159.
F4.06
Multipoint V/F
voltage point 2
0.0% to 100.0%
0.0%
122
160.
F4.07
Multipoint V/F
frequency point 3
F4.05 to b0.04 (rated
motor frequency)
0.00Hz
122
161.
F4.08
Multipoint V/F
voltage point 3
0.0% to 100.0%
0.0%
122
162.
F4.09
Slip compensation
coefficient
0% to 200.0%
0
.
0%
123
