Powtran PI9000 series User Manual

Chapter 5 Function parameter
111
bits
keep
Stop keep
0
Stop order zero clear
1
Stop over zero clear
2
Hundre
d bits
Reserve
Thousa
nd bits
Reserve
Note:
“Superscript
3
”means software version of C3.00 and above with MCU
keyboard have such function.
5-2-4.Output terminals: F2.00-F2.19
Code
Parameter name
Setting range
Factory
setting
Change
Limit
F2.00
SPB terminal output mode
selection
High-speed pulse output
0
0
☆
Switching quantity
output
1
SPB terminal is a programmable complex terminals, it can be used as an output terminal
of high-speed pulse, also an switching output terminal of collector open circuit.
As a high-speed pulse output, the highest frequency of output pulse is 100kHz, please
see the instructions of F2.06 for high-speed pulse output function.
F2.01
Switching quantity
output function selection
(collector Open circuit
output terminals)
0 to 40
0
☆
F2.02
Relay 1 output function
selection
(TA1.TB1.TC1)
0 to 40
2
☆
F2.03
Undefined
F2.04
SPA output function
selection (collector Open
circuit output terminals)
0 to 40
1
☆
F2.05
Relay 2 output function
selection
(TA2.TB2.TC2)
0 to 40
1
☆
The above five function codes are used to select five digital output functions.
Multifunction output terminal function is described as follows:
Set
value
Function
Description
0
No output
No output action
1
Inverter in service
The inverter is in operation with output
frequency (zero), and outputs ON signal.
